Unmatched Scalability and Performance
2U, 2-socket platform that provides scalability and performance to adapt to a variety of applications. Drive demanding workloads by latest 4th or 5th generation Intel® Xeon® Scalable Processors with up to 60 / 64 cores per CPU.
Accelerate IT Transformation
Transform your data center for modern operations and drive demanding workloads with 32 DIMM modules (up to 8TB). DDR5 DIMM memory provides fast, high capacity for memory intensive workloads.
Extensive Expandability
Maximize storage performance with up to 12x 3.5” or up to 24x 2.5” storage devices and ensure application performance scales to meet demands. Up to 8 PCIe 5.0 slots and OCP v3 adapters also ensure enough growth opportunities.
Agile Infrastructure Management
As you scale your infrastructure, scale your profitability with embedded intelligence from iRMC S6 as well as Infrastructure Manager (ISM) which enables organizations to have centralized control over the infrastructure using a single user interface.
| Chipset | Intel® C741 |
|---|---|
| Mainboard Type | D3983 |
| Product Type | Dual Socket Rack Server |
| Processor | Intel® Xeon® Bronze 3xxx processor, Intel® Xeon® Silver 4xxx processor, Intel® Xeon® Gold 5xxx processor, Intel® Xeon® Gold 6xxx processor, Intel® Xeon® Platinum 8xxx processor 1 - 2 x Intel® Xeon® Processor Scalable Family |
| Memory | 16 GB - 8 TB, DIMM (DDR5) |
| Memory slots | 32 (16 DIMMs per CPU, 8 channels with 2 slots per channel) |
| Memory Protection | ECC, Memory Scrubbing, SDDC, ADDDC (Adaptive Double DRAM Device Correction), Memory Mirroring support |
| Drives (optional) | LTO9HH Ultrium, 300 MB/s, 18 TB, SAS 12Gb/s DVD supermulti, ultraslim, SATA I LTO7HH Ultrium, 300 MB/s, 2,500 GB, SAS 6Gb/s LTO8HH Ultrium, 300 MB/s, 12 TB, SAS 6Gb/s |
| PCI-Express 4.0 x16 | 1 x Low profile |
| Accessible Drive Bays | 1 x 5.25/9.5mm for DVD-RW/Blu-ray 1 x 5.25/0.4-inch for CD-RW/DVD |
| Optional Accessible Drives | ODD 5.25" possible ODD 5.25" NOT possible All possible options described in relevant system configurator. |
| Storage Drive Bays | up to 16x 2.5-inch, 24x 2.5-inch, 10x 3.5-inch or 12x 3.5-inch base units 10 x 3.5-inch hot-plug SAS/SATA 12 x 3.5-inch hot-plug SAS/SATA 16 x 2.5-inch hot-plug SAS/SATA 16 x 2.5-inch hot-plug SAS/SATA/PCIe 24 x 2.5-inch hot-plug SAS/SATA |
| LAN Controller | 1 x 1 Gbit/s onboard, Dynamic LoM via OCP slot; OCPv3 compliant, Optional OCP adapters:, 4 x 1 Gbit/s Ethernet (RJ45), 2 x 10 Gbit/s Ethernet (RJ45), 4 x 10 Gbit/s Ethernet (RJ45), 2 x 10 Gbit/s SFP+, 4 x 10 Gbit/s SFP+, 2 x 25 Gbit/s SFP28, 4 x 25 Gbit/s SFP28, 2x 100 Gbit/s QSFP28 |
| Remote Management | Integrated Remote Management Controller (iRMC S6, 1024 MB attached memory incl. graphics controller), IPMI 2.0 compatible |
| USB ports | 5 x USB 3.0 (2x front, 2x rear, 1x internal) |
| Graphics | 2 x VGA (thereof 1x front optional - not for base unit with 12x 3.5” and 24x 2.5" drives) |
| Management LAN (RJ-45) | 1 x dedicated management LAN port for iRMC S6 (10/100/1000 Mbit/s) |
| Trusted Platform Module (TPM) | Infineon / TPM 2.0 module, FIPS; TCG compliant (option) |
| Power Supply Configuration | 1 x hot-plug power supply or 2x hot-plug power supply for redundancy |
| Active Power (max. configuration) | 2,608 W |
| Weight | max. 32 kg |
| Rack (W x D x H) | 482.5 mm (Bezel) / 435 mm (Body) x 800 x 86.9 mm |
| Mounting Depth Rack | 873.1 mm |
| DC Infrastructure Management | Infrastructure Manager (ISM) Essential Edition Advanced Edition |
| Server Management | ServerView Agentless Service (SVAS), ServerView ESXi CIM Provider, ServerView Installation Manager (SVIM), ServerView Update Manager Express (UME) |
| Operating system | http://docs.ts.fujitsu.com/dl.aspx?id=d4ebd846-aa0c-478b-8f58-4cfbf3230473 |
| Manufacturer warranty period | 3 years |
| Manufacturer warranty type | Onsite warranty |
| Service Lifecycle | at least 5 years after shipment, for details see https://support.ts.fujitsu.com/ |
| Service Weblink | http://www.fujitsu.com/emeia/products/product-support-services/ |
| Support Pack Options | Globally available in major metropolitan areas: 9x5, Next Business Day Onsite Response Time 9x5, 4h Onsite Response Time (depending on country) 24x7, 4h Onsite Response Time (depending on country) |
| Recommended Service | 24x7 Onsite Service with 4h Onsite Response Time |
